Chromatic aberration tshwm sim thaum lub teeb dhau los ntawm lub lens, ua rau sib txawv wavelengths ntawm lub teeb kom refracted ntawm cov ces kaum sib txawv, ua rau cov xim dispersion thiab cov duab distortion. Nyob rau hauv ib txoj kev, qhov no tuaj yeem tshwm sim raws li xim fringing thiab ntug plooj. ED iav pab tswj cov refraction ntawm lub teeb, txo cov chromatic aberration thiab ua kom muaj xim ntau dua, cov duab ntse dua, thiab txhim kho qhov pom tseeb.
BM-RS004(LX) 6-24x50ED Long Range Shooting Scopes feem ntau muaj cov yam ntxwv thiab qhov zoo hauv qab no:
Txo chromatic aberration thiab xim fringing: ED iav zoo txo cov chromatic aberration, ua rau cov xim raug dua, tshwj xeeb tshaj yog nyob rau hauv high-contrast thiab low-light tej yam kev mob.
Ua kom pom tseeb thiab ua kom pom tseeb: Los ntawm kev txo qhov cuam tshuam ntawm chromatic aberration, ED scopes muab cov duab pom tseeb dua thiab zoo dua nrog kev pom zoo ntawm cov ntsiab lus zoo.
Ntxiv qhov sib txawv: Kev txo qis chromatic aberration pab txhim kho qhov sib txawv, ua kom cov hom phiaj zoo li txawv thiab meej.
Haum rau kev soj ntsuam kom ntxaws thiab kev tua ntev ntev: ED scopes ua tau zoo hauv cov haujlwm uas xav tau cov ntsiab lus nthuav dav thiab cov hom phiaj ntev, xws li saib noog, yos hav zoov, thiab tua ntev.
Nws yog ib qho tseem ceeb uas yuav tsum nco ntsoov tias ED scopes feem ntau muaj cov khoom siv kho qhov muag zoo thiab tsim khoom, uas tuaj yeem ua rau tus nqi siab dua. Thaum lawv muab kev ua haujlwm zoo tshaj plaws ntawm qhov muag, qhov ua tau zoo yog nyob ntawm lwm yam ntawm cov peev txheej, xws li txheej txheej, kev nthuav dav, thiab lub lens zoo.
Khoom Specification
| Yam khoom NO | BM-RS004 (LX) |
| POWER X OBJECTIVE LENS | 6-24x50ED |
| TUBE DIAMETER (MM) | 34mm ib |
| Shock / Recoil Rating (hauv Gs): | 1500G / 500 zaug |
| FIELD OF VIWW (FT / 100 YDS) | 20 88-5.22 ft: @100 Yards |
| Qhov muag RELIEF | 3.5 nti |
| Txoj hauj lwm Reticle | Thawj Focal Plane |
| Zero nres | AZS Zero Stop System |
Khoom Khoom
1.Magnification:6-24x
2.Txoj kab uas hla: 50 mm
3. Qhov muag nyem: 3.5 nti
4.Field of View 20.88-5.22 ft: @100 Yards
5. Tube Loj: 34 mm
6.Turret Adjustment:0.1MRAD
7.Reticle Position: Thawj Focal Plane
8.Reticle Paub meej: VPR MRAD
9.Zero Nres: AZS Zero Stop System
10.Zero Reset: Yog
11.Elevation Adj. Ntau yam: 100MOA
12.Windage Adj. Ntau yam: 50MOA
13.Txhim Kho Ib Txwm Tawm: 25 MOA
14.Parallax: Sab Parallax Kho 25Yds - Infinity
15.Illuminated Reticle: Liab (yeem nrog)
16.Length: 14.1 nti
17. Xim: Matte Dub
18. Nyhav: 36.6 oz
19. Waterproof: IPX7
20.Shock / Recoil Rating (hauv Gs): 1500G / 500 zaug
21. Roj teeb: CR2032
22.Coating txoj kev: 16-19 siab ntshiab anti-reflection ntsuab zaj duab xis
Daim ntawv thov tua / tua
